Coating And Powder Spraying Equipment

1.Characteristics of coating and powder spraying equipment

Efficiency

Coating and powder spraying equipment can achieve rapid coating. Its spray gun can evenly spray a large amount of powder coating onto the surface of the workpiece in a short period of time. For example, on some large-scale metal furniture production lines, automated powder coating equipment can complete the spraying of a large furniture component in minutes, greatly improving production efficiency.

Environmental friendliness

Powder coating itself does not contain organic solvents, and almost no volatile organic compounds (VOCs) are generated during the spraying process. Compared to traditional liquid coatings, this has much less environmental pollution. For example, in the field of automotive parts coating, the use of powder coating equipment can reduce the emission of harmful gases and meet increasingly strict environmental requirements.

High coating quality

Powder coating can form a uniform and thick coating. It can cover the surface defects of the workpiece well, and the coating has strong adhesion. For example, in the coating of aluminum alloy profiles for construction, the surface coating of the profiles after powder coating is smooth and flat, with good weather resistance and corrosion resistance, which can effectively protect the profiles.

Economic viability

The utilization rate of powder coating is relatively high. Due to the ability of powder spraying equipment to recover powder that has not adhered to the workpiece, and to reuse it after screening and other treatments, the general powder utilization rate can reach over 95%. This reduces paint waste and, in the long run, saves production costs.

2.Components of coating and powder spraying equipment

（1） Powder spray gun

Manual powder gun

Manual powder gun is mainly used for small workpieces or some local areas that require high spraying accuracy. It consists of gun body, nozzle, electrode needle and other parts. The operator manually controls the angle, distance, and spraying time of the spray gun to achieve powder spraying. For example, in the painting of some handicrafts, craftsmen can use manual powder guns to finely paint the details of the handicrafts.

Automatic powder gun

Automatic powder guns are usually installed on spraying equipment in automated production lines. It can automatically spray the workpiece according to the preset program. Its structure is more complex, generally including high-pressure generator, powder pump, fluidization device, etc. In the car body painting production line, the automatic powder gun can quickly and evenly spray the car body according to the set trajectory and parameters.

（2） Powder supply device

Powder bucket

A powder bucket is a container for storing powder coatings. It is generally made of stainless steel material to prevent powder coating from being contaminated. There is a stirring device inside the powder bucket to prevent powder coating from clumping. For example, in large industrial painting workshops, the capacity of powder drums can reach hundreds of liters, which can meet long-term production needs.

Powder supply pump

The function of the powder supply pump is to transport powder coating from the powder bucket to the spray gun. Common ones include Venturi pumps and screw pumps. The Venturi pump uses the negative pressure generated by high-speed airflow to transport powder, while the screw pump pushes the powder forward through the rotation of the screw. In practical applications, the appropriate powder supply pump should be selected based on the characteristics and spraying requirements of different powder coatings.

Fluidization device

The fluidization device is designed to keep the powder coating in a good fluidized state in the powder bucket. It injects an appropriate amount of compressed air into the bottom of the powder bucket, making the powder coating liquid like and easy to transport by the powder pump. If the fluidization effect is not good, the powder coating may block the powder supply pipeline.

（3） Recycling device

cyclone separator

The cyclone separator is an important component in the recycling device. When the powder that does not adhere to the workpiece during the spraying process is sucked into the recycling system, it first enters the cyclone separator. In a cyclone separator, under the action of high-speed rotating airflow, larger particles of powder will be separated and settled at the bottom of the separator for recovery due to different centrifugal forces.

Filter cartridge filter

After passing through the cyclone separator, fine powder particles will be further filtered through the filter element. Filter cartridges are generally made of materials such as polyester fibers, which can effectively filter out small powder particles. The filtered powder will fall back into the recycling system for reuse under the backwash effect of the filter.

Recycling pipelines and fans

The recycling pipeline is used to connect various recycling components and transport unattached powder to the recycling device. The fan provides power to create negative pressure within the recycling system, ensuring smooth recovery of the powder.

（4） Curing equipment

Curing oven

The curing oven is a key equipment for solidifying powder coatings into films. It usually uses electric heating or gas heating methods. In the curing furnace, the powder coating on the surface of the workpiece undergoes a chemical reaction under certain temperature and time conditions, forming a hard and smooth coating. For example, in the coating of metal products, the temperature of the curing furnace is usually set at around 180-200 ℃, and the curing time varies depending on factors such as the type of coating and the thickness of the workpiece.

Temperature control system

The temperature control system is used to precisely control the temperature inside the curing furnace. It includes temperature sensors, controllers, and heating elements. Real time monitoring of the temperature inside the curing furnace is achieved through temperature sensors, and the signal is fed back to the controller. The controller adjusts the power of the heating element based on the set temperature parameters to ensure temperature stability during the curing process.

3.Application industry of coating and powder spraying equipment

（1） Automotive and automotive parts industry

Car body painting

The car body requires good appearance and anti-corrosion performance. Powder coating equipment can provide uniform and high-quality coatings for car bodies. And due to its environmental friendliness, it meets the increasingly strict environmental standards of the automotive industry. For example, some electric vehicle brands extensively use powder coating equipment in the body painting process, which not only improves production efficiency but also reduces environmental pollution.

Automotive parts coating

Automotive components such as wheel hubs and engine mounts are also widely coated using powder coating equipment. For wheel hubs, the coating after powder coating can improve their wear resistance and corrosion resistance, while also achieving a variety of colors and appearance effects to meet the needs of different consumers.

（2） Home appliance industry

Refrigerator shell coating

The refrigerator shell needs a beautiful and durable coating. The powder coating equipment can provide a smooth and brightly colored coating for the refrigerator shell, and the scratch resistance of the powder coating can keep the refrigerator in good appearance during daily use. For example, some high-end refrigerator brands use powder coating technology to give the refrigerator shell a metallic texture while also providing good protective performance.

Washing machine shell coating

The shell of a washing machine often comes into contact with chemicals such as water and detergents, and needs to have good corrosion resistance. The coating formed by the powder spraying equipment can effectively protect the washing machine shell, and can easily achieve different colors and patterns of coating according to market demand.

（3） Metal furniture industry

Table and chair painting

Metal tables and chairs need to have good appearance and durability for both outdoor and indoor use. By using powder coating equipment for painting, various colors and textures of coatings can be provided for tables and chairs. For example, in the painting of outdoor metal tables and chairs, the weather resistance of powder coating can make them withstand sun and rain, extending the service life of tables and chairs.

File cabinet painting

The filing cabinet requires a sturdy coating to prevent scratches and corrosion. The powder coating equipment can provide high-quality coatings for filing cabinets, and can achieve different colors and glossiness coatings according to the needs of the office environment, such as matte, glossy, etc.

（4） Construction industry

Aluminum alloy door and window coating

Aluminum alloy doors and windows need to have good weather resistance and decorative properties. The coating provided by the powder coating equipment can effectively protect aluminum alloy doors and windows from external environmental erosion, while achieving a variety of color and texture effects that match the overall style of the building.

Curtain wall coating

The area of building curtain walls is usually large, and there are high requirements for the quality and appearance of coatings. The powder coating equipment can quickly and efficiently provide a uniform and beautiful coating for the curtain wall, and the aging resistance of the powder coating can ensure that the curtain wall maintains a good appearance during long-term use.
